KFA Xpedition 4 kit - Quick build Kit

What is included?

Xpedition 4 - Firewall back

Fuselage

• Carbon floorboards for cockpit and luggage, carbon glare shield, carbon centre console, carbon kick panels, carbon elevator trim tab.
• Carbon boot cowl
• Roof, turtle deck, butt-ribs and much more
• Control system including pulleys and cables for rudder.
• All hardware - bolts, nuts, washers, fittings and rod-ends.
• Fuselage stringers
• Two front seats, four point harness with fittings.
• Rear foldable bench seat.
• Electric trim servo (Does not include the button or indicator)
• Header tank with fuel low warning sensor installed
• Fuel valves and fuel lines from tanks to valves and header tank.
• Windscreen glass
• Door glass (Top and bottom)
• Roof and turtle deck windows
• Gas lifts for doors

Wings

• Including Quick build wings and wing rigging
• 2 x 27.7 gal fuel tanks
• Carbon leading edge cuff, wing tips, trailing edge cuff, aileron, flap and lift strut speed fairings
• Spars with brackets, rivets and bolts
• Lift struts

Landing gear

• Matco 8" rims
• Extended gear
• 31 x 10" bush wheels
• Dual piston brake callipers
• Complete KFA Buffalo suspension system with cabane
• Axles, bearings, bolts, nuts and other hardware

Covering kit

• KFA PU system- fabric, glue, pinked tapes, PU up to base color

Firewall Forward kit - UL 520T

• Bottom and top cowl
• Firewall engine mount
• Oil cooler and bracket
• Carbon landing light holders
• Naca duct for oil cooler
• Naca for air intake
• Airfilter box with air filter

Optional (ordered separately)

• Oil hoses with fittings
• Fuel pumps (Andair)
• Fuel pre-filters and high pressure filter

More firewall forward engine options available. Please call

What is not included in our kits? (We can supply all these)

• Engine
• Propeller
• Avionics
• Upholstery (Leather and fabric choices)
• Wiring and electrical components (Switches, batteries etc)
• Paint
• Instrument panel cutting
• Firewall forward fuel and oil lines including fittings

Terms and Conditions apply - E&OE
